TOA IP-100RM
TOA IP-100RM

TOA IP-100RM

Contact

IR-100RM is a network remote microphone. It can be used for general broadcasting and emergency broadcasting.

The microphone can receive messages from the server or other devices. It can also distribute these messages to the selected zone or all zones.

The status LED next to each button allows the operator to get the status of each zone and other operating status with just a glance.

Up to 1000 zones can be supported.

Categories: , , ,

Description

Specifications:

Power Source DC24V

Current Consumption Below 200mA (single IP-100RM), below 500mA (connected with 9 pieces of RM-110)

Audio Input 1V rms (Max: 2V rms), 10kΩ electronically balanced gooseneck microphone

Audio Output 1V rms, unbalance 600Ω or unbalanced, 11.25mW, 32Ω

Frequency Response
LINE IN (Sampling rate: 22k), 20Hz -10kHz
LINE OUT (Network broadcast) (MP3 / sampling rate: 44k), 40Hz – 20kHz
SPEAKER OUT(Network broadcast) (MP3/ sampling rate: 44k), 20Hz – 20kHz

Control Input Optic coupler shortage input, open voltage DC 5V, maximum shortage current ≤5mA

Built-in Monitor Speaker Maximum output 1W

Volume control Microphone volume control, monitor speaker volume control

Number of Function Keys 15 on single equipment. Expandable to 105 with 9 sets of RM-210 connected

Maximum Zoning Support 1000

Network I/F 10 BASE-T / 100 BASE-TX Auto Negotiation

Network Protocol UDP, ARP, ICMP, HTTP, IGMP

Operation Temperature 0°C to +40°C

Operation Humidity Less than 90% RH (no condensation)

Finish ABS resin, bluish gray

Dimensions ( W x H x D ) 190 x 76.5 x 215 mm (not included the gooseneck microphone)

Weight 0.8kg

Accessory –
